CPU
Installed Processors (Max): 0 (1)
Supported Processor Manufacturer: Intel
Supported Processors: Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors
64-bit Support: Yes
Socket: LGA1700
Rear Panel I/O Ports
USB Ports: 1 x USB-C 3.2
1 x USB 3.1
3 x USB 3.0
1 x USB 2.0
DisplayPorts: 1 x DisplayPort 1.4
HDMI Port: 1 x HDMI 2.1
Internal I/O Connectors
SATA Connectors: 4 x SATA
USB Connectors: 1 x USB-C 3.1 header (supports 1 port)
1 x USB 3.0 header (supports 2 ports)
2 x USB 2.0 headers (supports 4 ports)
Memory
Memory Bus Speed: Up to 7200 MT/s
Memory Type: DDR5
Motherboard
Northbridge: Intel B760
RAID Supported: Yes
RAID Format: RAID 0, 1, 5, 10
SATA Supported: Yes
Rear Panel I/O Ports
RJ-45 Ports: 1 x RJ-45
Audio Line In Ports: 1 x 3.5mm Jack
Audio Line Out Ports: 3 x 3.5mm Jacks
Microphone In Port: 1 x 3.5mm Jack
S/PDIF Port: 1 x S/PDIF Optical Out
Antenna Connector(s): 2 x SMA Antenna
Internal I/O Connectors
Front Panel Connectors: 1 x Front Panel
1 x Front Audio
Cooling Fan Support: 1 x CPU fan header
1 x CPU OPT fan header
1 x AIO pump header
4 x Chassis fan headers
Thunderbolt Port(s): 1 x Thunderbolt 4 header
Serial Connectors: 1 x COM header
Chassis Intrusion Connector: 1 x Chassis Intrusion header
Power Connector Port: 1 x 24-pin ATX
1 x 8-pin EPS
1 x 4-pin EPS
Other Connectors: 2 x M.2 slots, Key M, Type 2242/2260/2280 (PCIe Gen4)
1 x M.2 slot, Key M, Type 2242/2260/2280/22110 (PCIe Gen4)
3 x 3-pin ARGB LED headers
1 x 4-pin RGB LED header
Expansion
Number of PCI Express Slots: 1 x PCI Express 5.0 x16 slot
1 x PCI Express 3.0 x16 slot ( x4)
2 x PCI Express 3.0 x1 slots
